| Primary Power | DC 12V@3A-24V@1.5A，Power Max. 10W |
PoE | Supported IEEE802.3at/af compliant，Power Max.12W |
Operating Frequency/ Standards | 125KHz
13.56MHz: ISO14443 types A&B, ISO 15693
2.4GHz Bluetooth |
| RS-485 connection | RS-485 standard/ OSDP V2.0/ 2.2* |
| CPU | 1.2GHz Quad Core ARM Processor |
| NPU | 2.4 TOPs NPU |
Memory | 1GB RAM+ 8GB Flash |
| Camera | Face Automatic Exposure
Palm Automatic Exposure
Face Tracking
Palm Detection
WDR
50Hz/ 60Hz Anti-Flicker
Dual Camera
Output image 720x1280 pixels |
Ethernet Network Connection | Ethernet: 10 Base-T/ 100 Base-TX, Auto MDI/ MDIX |
| Data Protection | Complies with TLS 1.2 for end-to-end secure communication channel
(Secured Communication between Standalone Terminal & Server)
AES128 (Secured Communication between the Standalone Terminal &
OSDP Readers & Access Control Panels) |
| Number of Ports | 1*TCP/ IP
1*RS-485
4ch TTL Inputs
1ch TTL Output
2 relays |
| Inputs | Wiegand, Button, Sensor, Aux Inputs |
| Outputs | Wiegand, Lock Relay, Alarm Relay (Relay via dry contacts) |
Normally Open Contact Rating | 5A @30Vdc resistive |
Normally Closed Contact Rating | 5A @30Vdc resistive |
Tamper Switch | Magnetic tamper detection system |
On-Board Monitor | Size: 5.0", Resolution: 720*1280 |
Audio Indicator | Internal speaker with adjustable intensity (Configurable on UI) |
| MIC | Supported |
Video Phone | Support Standard SIP V2.0 |
User Capacity | 100,000 |
RFID Card Capacity | 100,000 |
Maximum RFID Card Number Length | Wiegand In & Out (up to 64 bits) |
Face Capacity | 50,000 (1:N)/ 100,000 (1:1) |
Palm Capacity | 5,000 (1:N)/ 100,000 (1:1) |
RFID Reading Distance | 13.56MHz & 125KHz: Up to 1.96"/ 50 mm (depending on environment and transponder) |
Face Authentication Distance | 15.7" - 55.1" (40cm - 140cm) |
Face Authentication Posture Adaptability | Yaw ≤ 30°, Pitch ≤ 30°, Roll ≤45° |
Face Authentication Accuracy | True Accept Rate (TAR)=99%, False Accept Rate(FAR)=0.01% |
Face Authentication Mode | 1:1, 1:N |
Face Authentication Speed | < 100ms (Field Test Result) |
Face Authentication Liveness Detection | Yes (Infrared-visible light mode, Infrared Light Mode) |
Face Mask Detection | Yes |
Palm Authentication Distance | 7” -15.7” (18cm - 40cm) |
Palm Authentication Posture Adaptability | Yaw ≤ 45°, Pitch ≤ 30°, Roll ≤ 90°, Bend ≤ 30° |
Palm Authentication Accuracy | True Accept Rate(TAR)=98.7%, False Accept Rate(FAR)=0.01% |
Palm Authentication Mode | 1:1, 1:N |
Palm Authentication Speed | < 140ms (Field Test Result) |
Palm Authentication Liveness Detection | Yes (Infrared Light Mode) |
Recommend Installation Height | 55" (140cm) (Using the plate with tilt angle) 59" (150cm) (Plate with horizontal angle) |
Transaction Buffer | Records: 1,000,000 |
Access Group | 99 |
On-Board Access Point Control | 1 access point on board |
On-Board Reader Support | 1 (OSDP over RS-485) or 1 (Wiegand Input) |
Protection / Resistance | Weather & Dust Proof Protection Rating compliant with IP66 |
