AMT-PVS-50
Processor | 800MHZ Dual Core Cortex A53 Processor, 1.5 TOPs NPU |
Memory | 256MB RAM and 256MB Flash |
Camera | 1.3MP infrared camera; 1.3MP visible light camera |
Interface | USB 2.0 |
Communication | UVC and HID Protocol |
Power Supply | DC 5.0V/2.0A |
Power Consumption | < 2W (standby); < 3W (operation) |
Visual Indicator | Steady Green LED: Normal Status
Steady Red LED: Authentication in Progress
Steady Orange LED: Error/ Fault
Steady White LED: Object nearby detected |
Supported OS | Android 7, 8, 9, 10; Windows 7, 10, 11; Linux (on request) |
Operating Temperature | -10°C ~ 55°C / 14°F~ 131°F |
Storage Temperature | -40°C to 85°C / -40°F to 185°F |
Operating Humidity | 15% ~ 95% RH (Non-condensing) |
Dimensions | 62.0(L) x 62.0(W) x 20.0(H) mm (±1mm) |
Weight | 97g |
Certifications(s) | CE, FCC, RoHS, WHQL |
