Armatura-One Security Platform
Armatura One
Armatura One is the ultimate “All-in-One” web-based security platform developed by Armatura. It contains multiple integrated modules: Personnel, Access Control, Time & Attendance, Elevator, Visitor, Parking Management, Video Management System, Office, Entrance Control, Information Screen, Defence, Data Monitor, Building Automation and Intrusion.
Armatura-one-product-page-banner_1920x700-7
Armatura-one-product-page-banner_1920x700-6
Armatura-one-product-page-banner_1920x700-5
Armatura-one-product-page-banner_1920x700-4
Armatura-one-product-page-banner_1920x700-3
Armatura-one-product-page-banner_1920x700-2
Armatura-one-product-page-banner_1920x700-1
Parameters
Armatura One Security Platform


Operating System

Server-Side
Microsoft Windows Server 2012(64-bit)
Microsoft Windows Server 2016(64-bit)
Microsoft Windows Server 2019(64-bit)
Microsoft Windows 10 20H2 or later(64-bit)
Microsoft Windows 11(64-bit)
* Mac Boot Camp is not supported
Suggested Browser for Client-Side
Chrome 33 or later,
Safari 6.1.3 or later
MS Edge 88 or later
Firefox 64.0 or later
Database
PostgreSQL ver.9.6 (built-in),MS SQL 2005/2008/2012/2019 (Supported),Oracle 11g/12c (Supported)
Maximum Supported Clients (Simultaneously)
5,000
Maximum Supported Personnel
1,000,000
Maximum RFID Cards
1,000,000
Maximum Passwords
1,000,000
Maximum Fingerprints
1,000,000
Maximum Faces
1,000,000
Maximum Access Controlled Doors
10,000
Maximum Access Control Levels
Unlimited (Upon server and network performance)
Maximum Attendance Points
10,000
Maximum Visitors (Monthly)
1,000,000
Maximum Surveillance Cameras
5,000
Maximum Intelligent Video Servers
50
Maximum Controlled Floors
128 (8 pcs AHEB-1616 / 16 pcs AHEB-0808)
Maximum Controlled Outputs
Unlimited (Upon server and network performance)
Maximum Inputs
Unlimited (Upon server and network performance)


Download
Armatura One Introduction Guide 20221123
15.77MB
11 / 23 / 2022
Armatura One 5 Fold Brochure 20230310
7.53MB
03 / 10 / 2023
ARMATURA One User Manual 20221125
62.71MB
11 / 25 / 2022
ARMATURA ONE Datesheet 20240827
12.93MB
06 / 13 / 2024
