Armatura AMT-PVR-50_DataSheet_20240824
0.88MB
08 / 29 / 2024
Added Successfully
Processor | 800 MHz Dual Core Cortex A53 Processor, 1.5 TOPs NPU |
Memory | 256MB RAM and 256MB Flash |
Camera | 1.3 MP infrared camera; 1.3MP visible light camera |
Interface | USB 2.0 |
Operating Frequency/
Standards | 125KHz
13.56MHz: ISO14443A, ISO14443B, JIS X6319-4, ISO15693 |
Card Type | ID card, IC card, MF card |
Communication | UVC and HID Protocol |
Power Supply | DC 5.0V/ 1.0A |
Power Consumption | < 2.0W (standby); < 4.0W (operation) |
Operating Temperature | -10°C to 55°C / 14°F to 131°F |
Storage Temperature | -20°C to 65°C / -4°F to 149°F |
Operating Humidity | 15% to 95% RH ( non-condensing) |
Dimensions | 85.0 (L) x 85.0(W) x 28.7(H) (±1 mm) |
Weight | 150g |
Certifications(s) | CE, FCC, RoHS |
