| General Information | ||
| Interface | USB 2.0 | |
| Power Supply | DC 5.0V/ 400mA | |
| Power Consumption | <1.1W (standby); <2.0W (operation) | |
| Operating Temperature | -10°C ~ 45°C / 14°F ~ 113°F | |
| Storage Temperature | -20°C to 80°C / -4°F ~ 176°F | |
| Operating Humidity | 0 ~ 90% RH | |
| Module Dimensions | Module: 60.0(L) * 22.0(W) * 18.3(H) mm (±1mm) | |
| Reader: 95.5(L) * 29.0(W) * 26.4(H) mm (±1mm) | ||
| SDK | Armatura FaceLite SDK 12.0 | |
| Certification | CE, FCC, RoHS, WHQL | |
| Sensor | ||
| Camara Type | Visible Light Camera | Infrared Light Camera |
| CMOS | 1 / 2.7” HDR | |
| Dynamic Range | 83dB | |
| Optical Wavelength | 440 nm ~ 650 nm | 850 nm |
| Image Type | 24-bit RGB true color | 256 Grayscale Levels |
| Image Resolution | 720W * 1280H | 720W * 1280H |
| Default Output Format | MJPEG | |
| Distortion Rate | ≤1% | |
| Field of View | Horizontal: 40°; Vertical: 65°; Diagonal: 74° | |
| Maximal Frame Rate | 12 fps | |
| Recognition Distance | 40cm ~ 90cm /16 inch ~ 35 inch |
