AMT-FAS-35

Parameters

AMT-FAS-35

Processor	1.2GHZ Quad Core ARM Processor, 2.4 TOPS NPU
Memory	1 GB RAM & 512MB Flash Storage
Camera	1.3 MP infrared light camera; 2.0 MP visible light camera.
Interface	USB 2.0
Communication	UVC and HID Protocol
Power Supply	DC 5.0V/2.0A
Power Consumption	< 2.5W (standby); < 3.5 W (operation)
Operating Temperature	-10°C ~ 55°C / 14°F ~ 131°F
Storage Temperature	-40°C ~ 85°C / -40°F ~ 185°F
Operating Humidity	15% ~ 95% RH
Dimension	79.1L x 27.0W x 21.1H (mm)
Certifications	CE, FCC, RoHS, WHQL
Sensor
Camara Typ	Visible Light Camera	Infrared Light Camera
CMOS	1/2.8” HDR CMOS, 2.0MP	1/4” CMOS, 1.3MP
Dynamic Range	HDR mode 106dB	100dB
Optical Wavelength	440 nm ~ 650 nm	940 nm
Image Type	24-bit RGB true color	256 Grayscale Levels
Illumination Range	0.01 Lux to 50,000 Lux	0.01 Lux to 50,000 Lux
Exposure Mode	Auto Expose on Region of Interest (AE on ROI)
Image Resolution (Pixel)	Raw: 1080W*1920H	Raw: 1080W * 1280H
	Output: 720W * 1280H	Output: 720W * 1280H
Frame per second	15
Distortion Rate	≤ 0.5%
Built-In Algorithms
Recognition Distance	40cm - 120 cm
Posture Adaptability (by Default)	Yaw ≤ 30°, Pitch ≤ 30°, Roll ≤45°
Accuracy*	TAR=99%@FAR=0.01%
Recognition Mode	1:1, 1:N
Recognition Speed	< 100ms
Face Attribute	Age, Gender, Expression classification
Liveness Detection	Infrared-visible light mode & Infrared light mode
Face Mask Detection	Yes
1:N Capacity	30,000

[*] The accuracy is assessed on the proprietary infrared light face image data set.

TAR: True Acceptance Rate, FAR: False Acceptance Rate.
