EP30CF multi-tech fingerprint reader A&E Specifications Ver1.2 20250417
1.28MB
04 / 24 / 2025
Added Successfully
Internal Number | EP30CF |
Operating Frequency / Standards | 125 kHz
13.56 MHz
2.4 GHz Bluetooth®5.2 |
Functions | RFID, Bluetooth, Fingerprint |
Communications & Panel Connection | OSDP (v2.2) via RS485 |
RFID Reading Distance | 13.56MHz & 125kHz: Up to 2.3"/60 mm (depending on environment and transponder)
Up to 393.7"/ 10m with a Bluetooth Smartphone (configurable distances on each reader |
Data Protection | AES128 (Secured Communication between Reader & Controller)
Secure Data Storage in EAL6+ Certified Crypto Chip |
Fingerprint Algorithm | AMTFingerprint v10.0 |
Visual Indicator | RGB LEDs (Configurable By 'Armatura Connect' Mobile APP) |
Audio Indicator | Internal buzzer with adjustable intensity
(Configurable By 'Armatura Connect' Mobile APP) |
Power Requirement / Power Supply | 9 VDC to 24 VDC |
Operating Temperature | -4°F - 131°F /-20°C to 55°C |
Dimensions (L*H*D) | With Metal Case: 2.59" L x 5.28" H x 1.54" D (65.9 x 134.2 x 39.1mm)
With Metal Case and Back Case: 2.48 L x 5.18 H x 1.57 D (63 x 131.5 x 40mm) Without Metal Case: 2.57" L x 5.26" H x 1.54" D (65.2 x 133.7 x 39.1mm) |
Tamper Switch | Magnetic tamper detection system |
Certifications | CE, FCC, UL294(Coming Soon)，RoHs3.0, WEEE, IEC EN/ BS EN 60839 Grade 4 |
Mounting | Back box for flush mount or surface mount on any flat surface mounting |
Protection / Resistance | Weather & Dust Proof Protection Rating compliant with IP65 |
