AMT-PIX-20
AMT-PIX-20
•Near-Infrared (NIR) camera with built‑in NIR lighting captures vein patterns beneath the palm at 960×1280 (raw) and 720×1280 (output)
resolution, delivering consistent results regardless of any environment lighting.
•Built‑in algorithms detect the palm, extract the vein template, and block spoofed prints or displays. On‑device processing: liveness
detection <20 ms (IR–visible and IR modes), template extraction <25 ms, 1:1 comparison <30 ms; performance measured at FRR 0.17% @
FAR 0.001% and the template format is compliant with ISO/IEC 19795‑2.
•Intuitive LED indicators (green, red, blue, white) guide users for optimal palm placement and provide instant visual feedback on recognition
status.
•Compatible with the MultiBio SDK, supporting development on major platforms including Windows, Android, and Linux (on request).
•Ultra-compact and lightweight design with a USB 2.0 interface for effortless integration into time attendance systems, access control
devices, identity verification terminals, and other hardware applications.
Enquire Now
Parameters
AMT-PIX-20
Processor

800 MHz Dual Core Cortex A53 Processor, 1.5 TOPs NPU

Memory

256MB RAM and 256MB Flash

Camera

1.3MP visible light camera

Interface

USB 2.0

Communication

UVC and HID Protocol

Power Supply

DC 5.0V/2.0A

Power Consumption

< 1.3 W (standby); < 2.5 W (operation)

Visual Indicator

Four-color status LEDs: Red (Failed); Blue ( Standby); Green (Success); White (Processing)

Supported OS

Android 7, 8, 9, 10; Windows 7, 10, 11; Linux (on request)

Operating Temperature

-10°C ~ 55°C / 14°F ~ 131°F

Storage Temperature

-40°C ~ 85°C / -40°F ~ 185°F

Operating Humidity

15% ~ 95% RH (Non-condensing)

Dimension

39(L) x 34(W) x 20.5(H) mm (±1mm) / 1.53" (L) x1.34"(W)x0.81"(H)(±0.04inch)

Certifications

CE, FCC, RoHS, WHQL, ISO/IEC 19795-2
